Text-based chat over WebSocket is just the beginning. Modern communication systems must support real-time voice and video features just like your favorite meeting apps.

And the global standard for real-time media transmission is WebRTC. But here’s the catch: WebRTC cannot initiate the connection by itself. It needs a mechanism called Signaling, and in this tutorial, we’ll use WebSocket as our signaling server.

This article will walk you through everything you need to know: From PeerConnection → ICE Candidates → Signaling → actual audio/video streaming all with real, production-grade Go code.

🔊 What is WebRTC?

WebRTC is a framework for real-time peer-to-peer communication directly between browsers.

✨ Key features:

• Low-latency audio/video (less than 100ms)
• True peer-to-peer connection (no central server for media)
• Secure by default (encrypted media streams)

🤔 What about WebSocket?

WebRTC is purpose-built for real-time media transmission.

🛰 Components of WebRTC

• RTCPeerConnection
  Handles encrypted media connection between peers.
• ICE Candidate
  Determines possible network paths (LAN, Public IP, TURN server, etc.)
• SDP (Session Description Protocol)
  Describes media details (codec, bitrate, etc.)
• Signaling Server
  Responsible for exchanging messages like offer, answer, and ICE candidates between clients.

⚠️ WebRTC does not include signaling you need to implement it yourself.

🔄 Using WebSocket as Signaling Server

Connection flow:

1. 👤 Client A creates an offer and sends it via WebSocket
2. 🔁 Server forwards the offer to Client B
3. 👤 Client B replies with an answer
4. 🔄 Both clients exchange ICE candidates
5. ✅ Once handshake is complete → media streaming begins!

🧪 Go Example: WebSocket Signaling Server

type SignalMessage struct {
    Type string `json:"type"` // offer, answer, ice
    From string `json:"from"`
    To   string `json:"to"`
    Data json.RawMessage `json:"data"`
}

var clients = make(map[string]*websocket.Conn)

func signalingHandler(c *fiber.Ctx) error {
    conn, err := upgrader.Upgrade(c.Context(), nil)
    if err != nil { return err }

    clientID := c.Query("id")
    clients[clientID] = conn

    for {
        _, msg, err := conn.ReadMessage()
        if err != nil {
            delete(clients, clientID)
            return nil
        }

        var signal SignalMessage
        json.Unmarshal(msg, &signal)

        if target, ok := clients[signal.To]; ok {
            target.WriteMessage(websocket.TextMessage, msg)
        }
    }
}

🎧 Client-side Code (JavaScript)

1. Create PeerConnection

const pc = new RTCPeerConnection({
  iceServers: [{ urls: "stun:stun.l.google.com:19302" }]
});

pc.onicecandidate = event => {
  if (event.candidate) {
    socket.send(JSON.stringify({
      type: "ice",
      to: remoteUser,
      data: event.candidate
    }));
  }
};

2. Start Call and Send Offer

async function startCall() {
  const stream = await navigator.mediaDevices.getUserMedia({ video: true, audio: true });
  stream.getTracks().forEach(track => pc.addTrack(track, stream));

  const offer = await pc.createOffer();
  await pc.setLocalDescription(offer);

  socket.send(JSON.stringify({
    type: "offer",
    to: remoteUser,
    data: offer
  }));
}

🔐 Using TURN Server (When P2P Fails)

In some scenarios, P2P connection might fail due to:

• NAT restrictions
• Firewalls blocking ports
• Mobile networks

In such cases, you’ll need a TURN server to relay the media Examples:

• Coturn
• Twilio TURN Service
• Google Cloud WebRTC Infra

⚙️ Production-grade Best Practices

🚀 Challenge: Build Your First Video Call

✅ Implement a working prototype using:

• WebSocket → Signaling
• WebRTC → P2P connection
• ICE Candidates exchange
• Media streaming

Start with 1-on-1 calls → Expand to group call later!

🔮 Coming Up Next: WebSocket for IoT Device Networks

In the next episode, we’ll explore building a real-time IoT network with WebSocket:

• Manage thousands of devices (sensors, robots, smart home)
• Handle device auth & secure communication
• Optimize bandwidth for constrained networks

If you’ve made it this far you’re ready for real-time engineering at scale! 🎯
